Flicker Free LED Driver

30-40W Series

City skyline

Photo By: John Doe
Button

Flicker Free LED Driver 30-40W

Features

  • High performance, low THD, no flicker (depth of modulation) <0.5%
  • over current and short-circuit protection
  • For indoor use only in a dry and well-ventilated environment.
  • Do not use this driver in high-temperature or humid conditions

Input voltage

AC220-240Vac (Input voltage range: 198-264Vac)

Operating Temperature Range

-20°C to +50°C

Application

Commercial lighting, office lighting, decorative lighting, residential lighting.

Contextual Image

Various Product Models

The output current can be customized

Models Input Voltage Output Current Output Voltage Output Power
HY-LED600mA40FSA AC 220-240V 50Hz 600mA DC 33-46V 20-28W
HY-LED650mA40FSA AC 220-240V 50Hz 650mA DC 33-46V 21-30W
HY-LED700mA40FSA AC 220-240V 50Hz 700mA DC 33-46V 23-32W
HY-LED750mA40FSA AC 220-240V 50Hz 750mA DC 33-46V 25-35W
HY-LED800mA40FSA AC 220-240V 50Hz 800mA DC 33-46V 26-37W
HY-LED850mA40FSA AC 220-240V 50Hz 850mA DC 33-46V 28-39W
HY-LED900mA40FSA AC 220-240V 50Hz 900mA DC 33-40V 30-36W
HY-LED950mA40FSA AC 220-240V 50Hz 950mA DC 33-40V 32-35W
HY-LED1000mA40FSA AC 220-240V 50Hz 1000mA DC 33-40V 33-40W
HY-LED1050mA40FSA AC 220-240V 50Hz 1050mA DC 33-38V 35-40W

Suitable for commercial office space lighting, home, and decorative lighting

Homes, offices, showrooms, restaurants, supermarkets, and more
